Diagrams of Spacecraft Responses to Orbit Attitude Control Thrust

Diagrams shows Gemini Spacecraft Responses to Orbital Attitude Systems's thrusters. Firing of appropriate combination of the thrusters cause pitch, roll and yaw.



Catalog Date: 13 January 1964
Film Type: 4x5 BW
NASA image: S64-03507
