Apollo Overview
Artist concept of Command/Service Module & Lunar module docked

Artist concept illustrating the Command/Service Module and Lunar Module (LM) docked in the LM Adapter and Saturn S-IVB stage. The Command/Servce Module completes a turnaround maneuver after translunar injection, then the Commane Module docks nose-to-nose with the LM. After the transposition and docking, the S-IVB stage is jettisoned and the Apollo spacecraft continues in a coasting maneuver toward the moon.



Catalog Date: 01 December 1966
Film Type: 4x5
NASA image: S66-11000
